6910230 - PS 10 MarSurf set 2 µm |
6910232 - PS 10 MarSurf set 5 µm |
6910235 - MARSURF PS10 C2, TRANSVERSE DRIVE, 2UM PROBE |
| Measuring principle |
Stylus method |
Stylus method |
Stylus method |
| Probe |
Inductive skidded probe |
Inductive skidded probe |
inductive skidded probe |
| Measuring units |
metric/inches |
metric/inches |
metric/inches |
| Measuring range mm |
0,35 |
0,35 |
0.350 |
| Profile resolution |
8 nm |
8 nm |
8 nm |
| Filter according to ISO/JIS |
Gaussian filter as per ISO 16610-21 (formerly ISO 11562), special filter as per DIN EN ISO 13565-1, Lambda s filter as per DIN EN ISO 3274 (can be switched off) |
Gaussian filter as per ISO 16610-21 (formerly ISO 11562), special filter as per DIN EN ISO 13565-1, Lambda s filter as per DIN EN ISO 3274 (can be switched off) |
Gaussian filter as per ISO 16610-21 (formerly ISO 11562), special filter as per DIN EN ISO 13565-1, Lambda s filter as per DIN EN ISO 3274 (can be switched off) |
| Short stroke under ISO/JIS |
Selectable |
Selectable |
selectable |
| Traversing length according ISO 12085 (MOTIF) |
1 mm, 2 mm, 4 mm, 8 mm, 12 mm, 16 mm |
1 mm, 2 mm, 4 mm, 8 mm, 12 mm, 16 mm |
1 mm, 2 mm, 4 mm |
| Evaluation lenth In according to ISO/JIS |
1.25 mm, 4.0 mm, 12.5 mm |
1.25 mm, 4.0 mm, 12.5 mm |
1.25 mm, 4.0 mm |
| Number n of sampling length according to ISO/JIS |
Selectable: 1 to 16 |
Selectable: 1 to 16 |
selectable: 1 to 16 |
| Stylus |
2 µm |
5 µm |
2 µm |
| Measuring force (N) |
0,00075 |
0,00075 |
0.00075 |
| Calibration function |
Dynamic; Ra, Rz, Rsm |
Dynamic; Ra, Rz, Rsm |
dynamic; Ra, Rz, Rsm |
| Storage capacity |
Min. 1350 profiles, min. 500,000 results, min. 250 PDF records, expandable to 32 GB with Micro SD card |
Min. 1350 profiles, min. 500,000 results, min. 250 PDF records, expandable to 32 GB with Micro SD card |
min. 3900 profiles, min. 500,000 results, min. 1500 PDF records, expandable with microSD card up to 32 GB |
| Other |
Lock/password protected, date/time |
Lock/password protected, date/time |
Lock/password protected, date/time |
| System of protection |
IP 40 |
IP 40 |
IP 40 |
| Rechargeable batteries |
Lithium-ion battery, min. 1200 measurements |
Lithium-ion battery, min. 1200 measurements |
Lithium-ion battery, min. 1200 measurements |
| Wide range power supply |
100 to 264 V |
100 to 264 V |
100 to 264 V |
| Dimensions in mm |
160 mm x 77 mm x 50 mm |
160 mm x 77 mm x 50 mm |
160 mm x 77 mm x 50 mm |
|
